• 0.56
• Sloped Ceiling Adaptable: Yes
• Canopy Diameter: 6 x 0.75

Xtreme H2O Indoor/Outdoor Fan Dimensions

• Diameter: 65" Blade tip to blade tip
• Dimensions when using the included 6" down rod:
• Ceiling fan height: 13.50" From ceiling to bottom of the motor hub.
• Blade drop Height: 12.75" From ceiling to the bottom most part of the fan blades.
• Requires a 8' ceiling for proper mounting safety.
• Can be mounted on a vaulted ceiling.

Motor Information

• Strong and efficient DC motor DC123 x 30mm
• 6 speeds forward and reverse
• The motor is covered under a limited lifetime warranty and is available in 5 designer colors.

Fan Blades

• Xtreme H2O in the Coal finish comes with 8 sleek straight line modern blades.
• The blades are coal finish, color matched to the motor finish.
• The blade pitch is 9°
• The blade pitch creates an optimal airflow of 8252 CFM when used on the highest speed, while using only 32 watts of electricity!
• Lead wire 80"
• Blades are constructed of ABS material for maximum protection against the outdoor elements.

Control

• Full function Hand-held/wall control is included with the fan.
• 6 Speeds forward and reverse.
• Lights on/off with full range dimming.
• Bond Smart control adaptable, BD-1000

Light Kit

• Light kit not included.
• Optional Light kit available for indoor/outdoor use, K9886L-SI

Room Suggestion

• The Xtreme H2O is a great choice for large spaces that are up to and over 400 square feet.
• Recommended applications would be bedrooms, family or great rooms, large main suite, loft, gym or exercise areas, garage, barn, warehouse.
• Outdoor locations such as patios, porches, pergolas and decks.

Features

• UL listed for indoor and outdoor use.
• Available in 5 different finishes Brushed Nickel, Oil Rubbed Bronze, Smoke Iron, Coal and White.
• Cool modern design with an industrial look and feel.
• Large fan with great air movement.
• Wall/hand held control included.
• Strong DC motor
• 6" Down rod included
• Can be used with our without light kit.
• Wet location listed for direct water contact.

Seasonal Settings

• Reverse your fan blade direction with the change of seasons for maximum comfort and energy savings.
• Summer Setting - When looking directly up at your fan from below, the blades should be moving in a counter clockwise direction, pushing cool air down.
• Winter Setting - When looking directly up at your fan from below, the blades should be moving in a clockwise direction, pushing air upwards, circulating warm air from ceilings.
